FLYROTOR 280A HV Brushless ESC (6–14S) – 35A BEC, USB + Bluetooth, 700–800 Heli

Overview

Built for demanding 700–800 class helicopters and high-power HV systems.

The FLYROTOR 280A HV ESC is a high-power electronic speed controller designed for 700–800 class RC helicopters and large-scale electric aircraft.

Powered by a 32-bit RISC-V MCU at 120MHz, it delivers extreme current handling, fast response, and stable governor performance in demanding setups.

Integrated USB-C and Bluetooth provide direct configuration without additional hardware, while advanced telemetry and a high-output SBEC make it ideal for modern Rotorflight, EdgeTX, and ETHOS ecosystems.

Key Features

• Supports 6S–14S LiPo / LiHV
• 280A continuous / 350A burst
• Integrated 10A / 35A peak SBEC
• Adjustable BEC output: 7.5V / 8.0V / 8.5V / 12V
• Built-in USB-C + Bluetooth (no programmer required)
• Internal governor + Rotorflight compatibility
• Energy recovery braking + synchronous rectification
• Integrated flight data logging
• Heavy-duty aluminum case with 4510 cooling fan
• External motor temperature sensor support (NTC)

📱 Configuration & Apps

• Windows configuration app
• Android app (APK)
• iOS app — now available on the Apple App Store (https://apps.apple.com/cn/app/flyrotor-esc/id6761365354?l=en-GB)
• CLI tools (Windows / Linux / macOS)
• EdgeTX / ETHOS LUA script support

📡 Telemetry Support

• FLYROTOR (native)
• KISS Telemetry
• Futaba S.BUS2
• FrSky Smart Port (S.PORT)
• FlySky iBUS2
• TBS Crossfire (CRSF)
• Graupner HoTT

Performance & Control

• PWM frequency: 10–24kHz
• Throttle range: 1100–1940µs (default)
• Smooth soft-start + fast restart logic
• Adjustable governor P / I tuning
• Response tuning (1–15 scale)

Protection Systems

• Low voltage protection
• Overcurrent protection
• MOSFET temperature protection
• Motor temperature protection
• Stall / desync protection
• SBEC fault / overvoltage / backflow protection

Rotorflight / Modern Ecosystem Ready

• Full Rotorflight governor compatibility
• Clean telemetry integration into flight controller or radio
• Works with EdgeTX / ETHOS radios via LUA + telemetry

Configuration & Firmware

Download tools, firmware, and apps:
https://github.com/BskyRui/flydragon-downloads

File Types:

• .fw → USB wired flashing
• .ota → Bluetooth OTA update

Specifications

• Model: FLYROTOR 280A HV
• Input Voltage: 6–14S LiPo
• Current: 280A continuous / 350A peak
• BEC Output: 7.5V / 8.0V / 8.5V / 12V
• BEC Current: 10A continuous / 35A peak
• Size: 85 × 50 × 32mm (44.5mm w/ fan)
• Weight: ~270g (290g w/ fan)
• Input Wire: 8AWG (220mm leads)
• Cooling: Aluminum case + 4510 fan

Compatibility

• 700–800 class RC helicopters
• High-power electric fixed wing aircraft
• Rotorflight, Spirit, and modern FBL systems

⚠️ Important Notes

• High-power ESC — not beginner hardware
• Requires proper setup (motor, gearing, battery, cooling)
• Improper installation or configuration can cause damage or injury
• Follow manufacturer guidelines — use at your own risk
