SMC HCL-RS 22.2V 1600mAh 6S XT60 5" Quad / Drone FPV Racing Pack - 16343-6S1P

SMC HCL-RS 22.2V 1600mAh 6S XT60 5" Quad / Drone FPV Racing Pack

The SMC HCL-RS 1600mAh 6S FPV Racing Pack is built for 5" quad and drone pilots who want strong power, reliable punch, and consistent performance from their FPV racing packs.

Designed for FPV racing applications, this compact 6S LiPo pack delivers high burst output while keeping the size practical for 5" quad and drone builds.

Key Features:

• Designed for 5" quad / drone FPV racing
• High-performance 22.2V 6S LiPo battery
• 1600mAh capacity
• 343 burst power rating
• XT60 connector
• G10 top and bottom plates for added durability
• 12AWG wire for high-current applications

Specifications:

• Capacity: 1600mAh +/- 5%
• Voltage: 22.2V
• Configuration: 6S1P
• Connector: XT60
• Burst Power: 343
• Size: 40mm x 39mm x 79mm
• Weight: 240g +/- 5g
• Wire Size: 12AWG
• Charge Rate: 1C to 5C

Charging Note: Higher charge rates may reduce the amount of mAh put back into the pack and may reduce overall cycle life. For best battery longevity, charge at 1C when possible.

Product Code: 16343-6S1P

Connector Options and Fitment

Main connector: XT60.

Charging and Care

Standard LiPo pack (not LiHV): charge to a maximum of 4.20V per cell using a compatible LiPo balance charger. SMC recommends a 1C to 5C charge rate and cautions that higher rates can reduce usable capacity and cycle life.
